MAXHUB UC P10 Full HD 1080p Professional PTZ Camera With 12x Zoom For Medium And Large Rooms

احصل على عرض لشركتك

49.999 EGP

14 People watching this product now!

Description

MAXHUB UC P10 Overview:



MAXHUB UPC10 Professional PTZ Camera With 12x Zoom

The MAXHUB 1080p full HD 60fps UC P20 is the next-generation of video conferencing equipment. This premium 1080p full HD UHD camera ensures crystal-clear video in any environment. 12x optical plus 16x digital zoom guarantees sensational clarity with smooth and ultra-silent PTZ. With versatile outputs and plug-and-play simplicity, the UC P20 sets new standards for mid-to-large meeting rooms. The superior 8.51 megapixel CMOS image sensor ensures excellent UHD video quality of up to 1080p full HD at 60fps. 12x optical zoom delivers clarity at any distance. Industry-leading ISP with 2D & 3D DNR boosts the quality of any video meeting. Silent PTZ operation, with versatile wide viewing angles (FoV 72.5° viewing) combined with smooth pan and tilt control puts every meeting in incredible focus. Whisper-silent motor allows users to adjust angles and zoom performance without pulling attention away from the conversation. Choose from up to 255 preset camera positions to instantly find the angle that’s right for you.

Features

  • UltraHD 1080p Full HD Max Resolution
  • Sensor: 1/2.5 inch, CMOS, Max Effective Pixel: 8.51M
  • 12x Optical Zoom (16x digital zoom)
  • 2D & 3D Digital Noise Reduction
  • Color: Black

Connections

  • Network: 1×RJ45: 10/100/1000Mbps Adaptive Ethernet Port
  • I/O: 1×RS232 IN: 8pin Min DIN, Max Distance: 30m, Protocol: VISCA / Pelco-D / Pelco-P, 1×RS485: 3pin phoenix port, Max Distance: 1200m, Protocol: VISCA / Pelco-D / Pelco-P
  • Audio: 1×LINEIN: 3.5mm Audio Interface
  • HDMI: 1×HDMI: Version 2.0
  • 3G-SDI: 1×3G-SDI: BNC type, 800mVp-p, 75Ω.A long to SMPTE 424M standard
  • USB: 1×USB3.0: Up to 1080p full HD@60fps compressed video and 1080P original video can be output

Power

  • DC 12V
  • Connector: JEITA type (DC IN 12V)

Operating System Support

  • Microsoft Windows 7, Windows 8, Windows 10
  • Apple MacOS X, Linux, Android
  • Linux and Android
Pixel

207M

Video System

1080P, 720P, 540P, 480P, 360P, 240Petc

Sensor

1/2.7inch, CMOS

Scanning Mode

Progressive

Lens

12x, f3.5mm~42.3mm, F1.8 ~ F2.8

Digital Zoom

16x

Minimal Illumination

0.5 Lux @ (F1.8, AGC ON)

Shutter

1/30s~1/10000s

White Balance

Auto, Indoor, Outdoor, One Push, Manual, VAR(2500K~8000K)

Backlight Compensation

Support

Digital Noise Reduction

2D&3D Digital Noise Reduction

Video S/N

≥55dB

Horizontal Angle of View

72.5°~ 6.9°

Vertical Angle of View

44.8°~ 3.9°

Horizontal Rotation Range

±170°

Vertical Rotation Range

-30°~ +30°

Pan Speed Range

1.7°~ 100°/s

Tilt Speed Range

0.7°~ 28°/s

H & V Flip

Support

Image Freeze

Support

Number of Preset

255

Preset Accuracy

0.1°

Video Format

YUY2 (BULK): max to 1080P@30fps
YUY2 (ISOC): max to 1080P@30fps
H.264 AVC: max to 1080P@30fps
H.264 SVC: max to 1080P@15fps
MJPEG: max to 1080P@28fps

Operate System

Windows 7, Windows 8, Windows 10, MacOS X, Linux, Android

Color System / Compression

YUV 4:2:2 / H.264 / MJPEG

USB 3.0

1

RS232 IN

1

RS232 OUT

1

DC IN

1

Input Voltage

DC 12V

Dimensions

128.5×118×156.2mm

Weight

0.91Kg

Specification

Overview

Brand

MAXHUB

Overview

Brand

MAXHUB
