Product Overview:
| ● Printing speed 127mm/s Max. in its class | ● No ink or ribbon required , more environmentally friendly |
| ● Can contain up to 82 mm diameter paper roll | ● Over-heat prevented and durable print head |
Product Specification:
Model | XP-365B | |
Print mode | Label print mode | Receipt print mode |
Printing Features | ||
Resolution | 203 DPI | |
Printing method | Direct Thermal | |
Max.print speed | 127 mm/s | 220 mm/s |
Max.print width | 76 mm | |
Media | ||
Media type | Thermal roll paper, thermal adhesive paper | |
Media width | 20~82 mm | |
Media thickness | 0.06 ~ 0.19 mm | |
Media roll diameter | Max.82 mm | |
Supply method | Easy Paper Loading | |
Performance Features | ||
Ram | 4 M | |
Flash | 4 M | |
Interfaces | USB / USB+Lan / USB+WIFI/ USB+Bluetooth | USB+Lan+Serial/ USB+Serial+Lan+Bluetooth / USB+Serial+Lan+WIFI |
Sensors | Print head temperature sensor/ Paper end/ Cover open / Gap | Print head temperature sensor/ Paper end/ Cover open |
Drawer port | 1 ports (Pin 2 for cashdrawer) | |
Fonts/Graphics/Symbologies | ||
Character sizes | Commonly used in single-byte fonts; FONT 0 to FONT 8, K, TST24.BF2,TSS24.BF2 | |
1D barcode | CODE128、EAN128、ITF、CODE39、CODE39C、CODE39S、CODE93、EAN13、EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、CODABAR、POSTNET、UPC-A、UPCA+2、UPCA+5、UPCE、UPCE+2、UPCE+5、MSI、MSIC、PLESSEY、ITF14、EAN14 | |
2D bar code | PDF417、QRCODE、 DataMatrix | |
Emulaion | TSPL | ESC/POS |
Physical Features | ||
Dimension | 212*140*144mm (D*W*H) | |
Weight | 0.94 kg | |
Reliability | ||
Print head life | 100 km | |
Software | ||
Driver | Windows | |
SDK | iOS/ Android/ Windows | |
Power supply | ||
Input | DC 24V/2.5A | |
Environmental Conditions | ||
Operation environment | 5～45℃ Humidity: RH 20 ~ 80% | |
Storage environment | -40～55 ℃ Humidity:≤93% RH | |
