Mercury Elite 1500VA/900W Pro UPS

Description

Mercury Elite 1500 Pro 1500VA/900W UPS

The Mercury Elite 1500 Pro Line Interactive UPS is an advanced UPS design, with built-in AVR (automatic voltage regulator) to withstand the power voltage fluctuations that are common with our power supply. Other built-in protection measures to safeguard your appliances and also ensure the durability of the UPS include: overload protection, short-circuit protection, deep battery discharge protection and battery overcharge protection.

The Mercury Elite 1500 Pro Line Interactive UPS can support up to 900 W power output requirement. Backup time will depend on load, but up to 40 minutes is possible from this UPS.

We are the number one stop shop when it comes to mercury products. At GZ Supplies, We act with honesty and nurture strong relationships from large public companies to private customers ensuring we have an understanding of every client’s needs and always aim to exceed their expectations.

Features of Mercury UPS Elite 1500 PRO:

• Auto restart
• Built-in AVR
• Surge protection
• Data-line protection
• Overload protection
• Overcharge protection
• Short circuit protection
• Intelligent battery management
• Battery deep discharge protection

Specifications :

Brand	Mercury
Model	ELITE 1500 PRO
Input
Input Voltage	220VAC
Input Frequency	50Hz
Input Phase	Single Phase
power cord	Built-in Cable with Fuse
Input Voltage Range(May vary as per Country requirement)	140~300VAC
Output
Rating Output	1500VA
Wave Form	Battery Mode (Simulated sine Wave) AC Mode (Synchronize with Input)
Rating Voltage	220V
Output Range	220VAC – 11% to + 17% (Battery Mode)
Rear Output Socket	4x Universal – Battery Backup
Transfer Time	Typical 4-8ms
Communication Interface	Nil
Output Frequency
Rating Frequency	50Hz
Line Mode	Synchronize with the Utility
Battery Mode	50Hz±1Hz
Short Circuit Protection
Line Mode	FUSE & Firmware Protection
Battery Mode	Firmware Protection
Overload Protection
Line Mode	110%±5% (go to fault mode after 5 minutes) 120%±5% (go to fault mode immediately)
Battery Mode	85%±5% (shut down after 5 seconds) 100%±5% (shut down immediately)
Battery and Runtime
Rating	2x12V/8.2AH
Backup Time – Typical	30mins~40mins (Depending On Load)
Charging Current	About 1A at Normal Mode
Over Charge Protection	29V±0.2V(Stop Charging) <27V ±0.5V(Recharge)
Packaging
Dimension(mm)	388x203x260
Master Carton(mm)	425x403x280
Pack size per Master Carton(mm)	2
