General Features:

• Innovative energy-efficient technology saves power up to 73%
• Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
• Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
• Auto-MDI/MDIX eliminates the need for crossover cables
• Supports MAC address auto-learning and auto-aging
• Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps hardware
• Fanless design ensures quiet operation
• Desktop design
• Plug and Play design simplifies installation

Hardware Features:

Standards and Protocols

• IEEE 802.3, IEEE 802.3u, IEEE 802.3x
• CSMA/CD

Interface

• 8 10/100Mbps Ports, Auto-Negotiation, Auto-MDI/MDIX

External Power Supply

• 100-240VAC, 50/60Hz

Fan Quantity

• Fanless

Data Rates

• 10/100Mbps at Half Duplex; 20/200Mbps at Full Duplex

LED Indicator

• Power, 1, 2, 3, 4, 5, 6, 7, 8

Dimensions ( W x D x H )

• 5.3*3.1*0.9 in. (134.5*79*22.5mm)

Power Supply

• External Power Adapter

Software Features

• Transfer Method: Store and Forward

Advanced Functions

• Green Technology, saving power up to73%
• 802.3X Flow Control, Back Pressure
• Auto-Uplink Every Port
